Replaceable protective cover
Reliable Gearbox: 13,000 cycles before maintenance
Vane type high performance air motor same as industrial impact wrench
Capable of reaching high torque accuracy
Different reaction arm types and shapes available
Reduce operator fatigue and risks of MSDs
| Metric | Imperial | |
|---|---|---|
| Model | CP6641 | |
| Part number | 6151800110 | |
| Average air consumption | 23 l/s | |
| European Directives | 2006/42/EC (17/05/2006) | |
| European Sound standard | ISO 15744 | |
| European Standards | EN ISO 11148-6:2013 | |
| Free speed | 10 rpm | |
| Handle type | Pistol | |
| Height | 228 mm | 8.97 " |
| Length | 361 mm | 14.21 " |
| Maximum Torque (fwd) | 4100 Nm | 3100 ft.lbs |
| Maximum Torque (reverse) | 4100 Nm | 3100 ft.lbs |
| Net weight | 8.8 kg | 19.4 lb |
| Reaction bar | S-type | |
| Reversible | Reversible | |
| Side to center | 40 mm | 1.57 " |
| Socket retainer | Hole | |
| Sound DBA pressure | 90 db(A) | |
| Sound Power | 101 db(A) | |
| Sound pressure | 90 db(A) | |
| Sound uncertainty | 3 db(A) | |
| Square drive | 25 mm | |
| Torque preset # | Multi | |
| Vibration | <2,5 m/s² | |
| Vibration ISO | ISO 28927-2 | |
| Vibration uncertainty (K) | / m/s² | |
| Weight Including Reaction Arm | 10.8 kg | 23.8 lb |
| Weight w/o Reaction Arm | 8.8 kg | 19.4 lb |
| Width | 100 mm | 3.94 " |
| Working Torque Range (fwd) | 1000 - 4100 Nm | 738 - 3100 ft.lbs |
| Working Torque Range (reverse) | 1000 - 4100 Nm | 738 - 3100 ft.lbs |
