1/4" hexagonal Quick change
Double rocking dog clutch
Reversible one-hand
| Metric | Imperial | |
|---|---|---|
| Model | CP2136 | |
| Part number | 8941021360 | |
| Actual air consumption | 3.2 l/s | 6.78 cfm |
| Air inlet thread size | 1/4 " | |
| Bit holder | Quick Change Hexagonal Female | |
| Bolt size | M4-M6 mm | |
| Box dimensions | 245*70*65 mm | 9.65*2.76*2.56 " |
| Clutch type | Impact (Double Rocking Dog) | |
| Diameter | 20 mm | 0.785 " |
| Free speed | 10000 rpm | |
| Free speed air consumption | 4.16 l/s | 8.81 cfm |
| Handle type | Straight | |
| Height | 50 mm | 1.96850393700787 " |
| Length | 185 mm | 7.28346456692913 " |
| Max working torque | 21 Nm | 15.5 ft.lbs |
| Min working torque | 8 Nm | 5.93 ft.lbs |
| Min. hose size | 10 mm | 3/8 " |
| Net weight | 0.68 kg | 1.49779735682819 lb |
| Output drive | 1/4 " | |
| Over carton | 400*258*291 mm | 15.75*10.16*11.46 " |
| Screw type hard | yes | |
| Screw type soft | yes | |
| Screw type very soft | yes | |
| Sound Power | 100 db(A) | |
| Sound pressure | 89 db(A) | |
| Vibration | 7.4 m/s² | |
| Vibration ISO | ISO-28927-2 | |
| Vibration uncertainty (K) | 2.8 m/s² |
