| Model |
FLT-4-3 BF EC |
| Handle type |
Pistol |
| Square drive |
Sq 3/8" |
Sq 9.5 |
| Square drive |
Sq 9.5 mm |
Sq 3/8 |
| Working Torque Range (fwd) |
5 - 12 Nm |
3.7 - 8.8 |
| Free speed |
6200 rpm |
| Net weight |
0.97 kg |
2.14 lb |
| Length |
181 mm |
7.13" |
| Side to center |
22 mm |
0.87" |
| Actual air consumption |
6.7 l/s |
14.1 cfm |
| Min. hose size |
6.3 mm |
1/4" |
| Sound pressure |
74.7 db(A) |
| Sound Power |
85.7 db(A) |
| Vibration α (ISO-28927-2) |
< 2.5 m/s² |
| Vibration K (ISO-28927-2) |
0.4 m/s² |
| Socket retainer |
Pin (BF-Anvil) |
| Pulse type |
2-blade |
| Bolt size |
M5 - M6 |
No.10 -1/4 |
FLT-4-3 BF EC - Compact, accurate & long life, CE
