Part number
|
5412053594
|
|
|
Model
|
FW-44SA-1 BF
|
|
|
Handle type
|
Straight
|
|
|
Square drive
|
3/8"
|
9,5 mm
|
|
Square drive
|
9,5 mm
|
3/8
|
|
Working Torque Range (fwd)
|
6 - 12 Nm
|
4.4 - 8.9
|
|
Maximum Torque (fwd)
|
20 Nm
|
14.8 ft.lbs
|
|
Free speed
|
5700 rpm
|
|
|
Net weight
|
0.66 kg
|
1.46 lb
|
|
Length
|
207 mm
|
8.15"
|
|
Actual air consumption
|
5.8 l/s
|
12.4 cfm
|
|
Min. hose size
|
6.3 mm
|
1/4"
|
|
Sound pressure
|
86 db(A)
|
|
|
Sound Power
|
97 db(A)
|
|
|
Vibration α (ISO-28927-2)
|
5.5 m/s²
|
|
|
Vibration K (ISO-28927-2)
|
1.7 m/s²
|
|
|
Socket retainer
|
Pin (BF-Anvil)
|
|
|
Clutch type
|
Double hammers
|
|
|
Bolt size
|
M5
|
No.10
|
