| Part number | 5412052474 | |
| Model | FC-01-4 | |
| Blows per minute | 3000 | |
| Piston diameter | 20 mm | 0.787" |
| Stroke | 44.5 mm | 1 3/4" |
| Chisel rivet set shank | 14 x 45 | 0.551 x 1.772 |
| Shank | Chisels (round shank) | |
| Net weight | 2.6 kg | 5.7 lb |
| Length | 273 mm | 10.7" |
| Actual air consumption | 6.9 l/s | 14.8 cfm |
| Min. hose size | 9.5 mm | 3/8" |
| Sound DBA pressure | 95 db(A) | |
| Sound Power | 106 db(A) | |
| Vibration α (ISO-28927-10) | 8.1 m/s² | |
| Vibration K (ISO-28927-10) | 2.4 m/s² |
