Part number |
5412053599 |
|
Model |
FW-44SAD-10 N |
|
Handle type |
Straight |
|
Square drive |
1/4" Hex." |
Hex. 6.35 |
Square drive |
Hex. 6.35 mm |
1/4" Hex. |
Working Torque Range (fwd) |
5 - 10 Nm |
3.7 - 7.4 |
Maximum Torque (fwd) |
15 Nm |
11 ft.lbs |
Free speed |
5700 rpm |
|
Net weight |
0.66 kg |
1.46 lb |
Length |
207 mm |
8.15" |
Actual air consumption |
5.8 l/s |
12.4 cfm |
Min. hose size |
6.3 mm |
1/4" |
Sound pressure |
86 db(A) |
|
Sound Power |
97 db(A) |
|
Vibration α (ISO-28927-2) |
5.2 m/s² |
|
Vibration K (ISO-28927-2) |
1.7 m/s² |
|
Socket retainer |
Bit Shank (Hex) |
|
Clutch type |
Double hammers |
|
Bolt size |
M5 |
No.10 |
